BAW New Gasoline Automatic Ambulance with Slide Rail Infusion Technology
![[pics:title]](https://www.clwtrucksgroup.com/static/upload/image/20251112/1762960479288742.jpg)
![[pics:title]](https://www.clwtrucksgroup.com/static/upload/image/20251112/1762960479371550.jpg)
![[pics:title]](https://www.clwtrucksgroup.com/static/upload/image/20251112/1762960479212582.jpg)
![[pics:title]](https://www.clwtrucksgroup.com/static/upload/image/20251112/1762960479659748.jpg)
![[pics:title]](/static/upload/image/20251112/1762960479288742.jpg)
![[pics:title]](/static/upload/image/20251112/1762960479371550.jpg)
![[pics:title]](/static/upload/image/20251112/1762960479212582.jpg)
![[pics:title]](/static/upload/image/20251112/1762960479659748.jpg)
Vehicle Parameters | |
Vehicle Brand | BAW |
Curb Weight(kg) | 1700 |
Engine Power(kw) | 106 |
Gearbox | 6 Speed Manual Transmission |
Vehicle Size (mm) | 5240x1870x2110 |
Medical Bay Dimensions(mm) | 2500x1600x1520 |
Number of Axles | 2 |
Wheelbase (mm) | 3200 |
Number of Tires | 4 |
Tire Size | 215/65R16 |
Brake System | Disc Hydraulic Brake |
Technical parameter | |
Equipment Cabinet | a set of |
Automatic Boarding Stretcher | One |
Slide Rail Infusion Rack | Two |
Oxygen Cylinder | 10L Two |
Folding Seat | One |
Bench Seat | One |
Alarm Lamp | A Set Of |
Power Supply System | A Set Of |
Lighting System | A Set Of |
Interphone | A Set Of |
Sterilizing Lamp | One |
Fire Extinguisher | Two |
Negative Pressure Equipment | A Set Of |
Category | Item | Basic | Care | Premium |
Safety | ABS Brake System | ✓ | ✓ | ✓ |
Central Door Locking | ✓ | ✓ | ✓ | |
Driver Airbag | ✓ | ✓ | ✓ | |
Comfort | Power Windows | ✓ | ✓ | ✓ |
Remote Key | ✓ | ✓ | ✓ | |
Factory HVAC (Driver Cabin) | 2 sets | 2 sets | 2 sets | |
Triple Driver Seats | ✓ | ✓ | ✓ | |
Exterior | White Body + Red Reflective Strips | ✓ | ✓ | ✓ |
2/3 Frosted Medical Window Film | ✓ | ✓ | ✓ | |
Warning System | 100W Siren | ✓ | ✓ | ✓ |
Front 3-Eye Warning Light | ✓ | - | - | |
Rear Beveled Strobe Lights | 2 | 2 | 2 | |
Side Blue/White Strobe Lights | 6 | 4 | 4 | |
Electrical | Pure Sine Inverter (500W/1000W) | 500W | 500W | 1000W |
220V Sockets | 2 | 2 | 4 | |
12V Sockets | 1 | 1 | 2 | |
UV Disinfection Lamp | ✓ | ✓ | ✓ | |
Medical Cabin | Oxygen System (10L Cylinders x2) | ✓ | ✓ | ✓ |
Auto-loading Stretcher | ✓ | ✓ | ✓ | |
Sliding IV Pole | - | - | ✓ | |
Antibacterial Flooring (Blue) | ✓ | ✓ | ✓ |
Feature | Basic | Care | Premium |
Partition | Sliding Window Partition | PVC Partition | Polymer Hard Partition |
Storage | Left Medical Cabinet | Left Overhead Cabinet | Triple-layer Equipment Rack |
Oxygen System | 2 Ports + 1 Humidifier | 2 Ports | 2 Ports + Ventilator Port |
Seating | 1 Doctor + 2 Bench Seats | 1 Doctor + 2 Bench Seats | 3 Doctor Seats |
Ventilation | Bidirectional Fan | Bidirectional Fan | Electric Vent Fan |
Ceiling | Original Roof | Original Roof | Polymer Hard Top |
Item | Availability |
Negative Pressure System | Customizable |
Rear Step | ✓ |
Navigation + Rearview Camera | ✓ |
Stretcher Compartment | ✓ |
Scoop/Stair/Folding Stretchers | ✓ |
ABS Interior Trim | Care/Premium only |
Item | Description | Availability |
1 | Negative pressure system | Customizable |
2 | Rear-facing foldable seat | Optional |
3 | Stretcher compartment | Optional |
4 | Scoop/stair/folding stretchers | Optional |
5 | Middle/rear boarding steps | Optional |
6 | Three-tier equipment rack | (Care Model only) |
7 | Three-position adjustable stretcher | (Care Model only) |
