4x2 Diesel Rear-Loading Garbage Truck | Manual Transmission Compactor with Reinforced Powertrain
![[pics:title]](https://www.clwtrucksgroup.com/static/upload/image/20251012/1760250667719931.jpg)
![[pics:title]](https://www.clwtrucksgroup.com/static/upload/image/20251012/1760250667240199.jpg)
![[pics:title]](https://www.clwtrucksgroup.com/static/upload/image/20251012/1760250666597053.jpg)
![[pics:title]](https://www.clwtrucksgroup.com/static/upload/image/20251012/1760250667786329.jpg)
![[pics:title]](/static/upload/image/20251012/1760250667719931.jpg)
![[pics:title]](/static/upload/image/20251012/1760250667240199.jpg)
![[pics:title]](/static/upload/image/20251012/1760250666597053.jpg)
![[pics:title]](/static/upload/image/20251012/1760250667786329.jpg)
[VehicleTechnical Parameters] | |
Product Name | Compression Garbage Truck |
Kerb Weight (Kg) | 15600 |
Overall Dimensions (mm) | 11900*2550*3560 15600 |
Box volume (m3) | 20 |
Box thickness (mm) | Side 4 Bottom 5 |
Box Body Material Quality | T355 Manganese Steel |
Compression Density (t/m ³） | 0.6-0.8 |
Working ambient temperature (℃) | 20~45 |
Sewage Tank Capacity (L) | 1600 |
Filling cycle time (S) | ≤35 |
Compression cycle time (S) | ≤15 |
Uninstall cycle time (S) | 60 |
Operating Mode | Automatic+Manual |
Max Passengers Allowed | 2/3 |
[Chassis Technical Parameters] | |
Brand Name | JIEFANG |
Brake | Air Brake/Oil Brake |
Fuel type | Diesel |
Engine Power（kw） | 213 |
Front Axle/Rear Axle (t) | 5.5/Double 10 |
Gearbox Model | 9-Speed Manual |
Number of axes | 3 |
Wheelbase (mm) | 4350+1350 |
Number of tires | 10 |
Tire size | 11.00R20 |
