FAW Compaction Garbage Truck 8-12 Tons with Hydraulic System for Waste Management，Compressed Garbage Truck，Chengli Automobile Group Co., Ltd.

[VehicleTechnical Parameters]Product Namecompression garbage truckKerb Weight (Kg)15800Overall Dimen

Learn More

[VehicleTechnical Parameters]Product Namecompressed rubbish vehicleKerb Weight (Kg)3860Overall Dimen

Learn More

[VehicleTechnical Parameters]Product Namecompression garbage truckKerb Weight (Kg)10980Overall Dimen

Learn More

[VehicleTechnical Parameters]Product Namecompressed rubbish vehicleKerb Weight (Kg)10550Overall Dime

Learn More

[VehicleTechnical Parameters]
Product Name	compressed rubbish vehicle
Kerb Weight (Kg)	6495
Overall Dimensions (mm)	680025502950
Box volume (m3)	10
Box thickness (mm)	4 on the side and 4 at the bottom
Box Body Material Quality	Q345 manganese steel plate
Compression Density (t/m ³）	0.6-0.8
Working ambient temperature (℃)	-20~45
Sewage Tank Capacity (L)	600
Filling cycle time (S)	≤35
Compression cycle time (S)	≤15
Uninstall cycle time (S)	≤60
Operating Mode	Automatic + Manual
Max Passengers Allowed	3
[Chassis Technical Parameters]
Brand Name	1-FAW
Brake	Empty ship air brake/oil brake
Fuel type	diesel
Engine Power（kw）	110
Front Axle/Rear Axle (t)	4.5/9
Gearbox Model	8-speed transmission
Number of axes	2
Wheelbase (mm)	3800
Number of tires	6
Tire size	9.00R20

FAW Compaction Garbage Truck 8-12 Tons with Hydraulic System for Waste Management
